Complete Hybrid Solar Kit - 12 KW AC Output | Up To 45 kWh Battery Backup | EG4 PowerPro ESS, DIY Solar Kit
Sale

Complete Hybrid Solar Kit - EG4 PowerPro ESS | 12 kW AC Output | Up To 45 kWh Battery Backup [Kit-E0007]

$16,475.20
$14,987.25
$16,475.20
$14,987.25

Have a question? We're here to help.

Texas Based Phone Support: 903-441-2090
Email: sales@signaturesolar.com
Mon-Fri 8am-8pm CST
Sat 9am-2pm CST
SKU:
KIT-E0007-32-1X-4X
EG4 PowerPro Spec Sheet:
EG4 PowerPro Manual:
EG4 18KPV Spec Sheet:
EG4 18KPV Manual:
EG4 18KPV RSD Installation Guide:

Description

Choose the ultimate solar solution with our Complete Hybrid Solar Kit, featuring the innovative EG4 PowerPro ESS. Tailor your kit with Canadian Solar panels, or opt for no panels. This comprehensive kit includes EG4 18kPV Hybrid Inverter, PowerPro batteries, conduit boxes, PV wire, and essential tools for seamless installation. Take control of your energy needs with unmatched performance, enhanced safety features, and streamlined management.

This kit is designed for as a whole home solar kit with everything you need to power your life, regardless of your energy consumption.

Introducing the Complete Hybrid Solar Kit with EG4 PowerPro ESS!

Our comprehensive kit not only includes the EG4 PowerPro ESS, but it also offers you the freedom to select your preferred solar panels or opt for no panels at all. Additionally, you'll receive essential solar accessories, one conduit box for each battery, and your choice of either 50-foot or 100-foot PV wire. We also provide essential wiring tools to simplify your installation process.

Please note that you may need to purchase additional conduit.

EG4 PowerPro ESS | 14.3 - 28.6kWh Capacity | EG4-18Kpv & EG4-PowerPro WallMount Battery The EG4 PowerPro ESS is a game-changing solution that seamlessly combines the power of the EG4 18kPV All-In-One Hybrid Inverter and the EG4 PowerPro 14.3kWh Battery. With a modular design and integrated conduit box, this tailored kit offers advanced inverter technology and cutting-edge battery solutions, allowing you to harness, manage, and store solar energy to meet your specific needs.

Key Features:

Unmatched Performance

  • Over 8000 cycles at 80% depth-of-discharge for long-lasting energy reliability.
  • Harness up to 12,000W of continuous output with the EG4 18kPV inverter.
  • Closed-loop communication ensures precise energy coordination.
  • EG4 PowerPro 14.3kWh Battery delivers uninterrupted power.
  • Stack multiple EG4 18kPV units for enhanced power capacity.

Enhanced Safety

  • EG4 PowerPro features integrated self-heating for low-temperature resilience.
  • Perfect for outdoor applications, built to withstand various weather conditions.
  • Innovative total emergency stop function for safety and compliance.
  • Benefit from a 10-year warranty provided by EG4 Electronics.
  • Dual onboard fire arrestors ensure fail-safe protection.

Streamlined Management

  • EG4 18kPV eliminates the need for charge controllers or transformers.
  • Enjoy plug-and-play installation for immediate energy access.
  • Conduit box helps facilitate future system upgrades easily.
  • User-friendly LCD interface for intuitive system monitoring.
  • Manage energy from storage and grid simultaneously.

Comprehensive Certifications

The EG4 18kPV is ETL & cETL certified and complies with national and international standards for safety and reliability when connected to the grid.

  • Safety - UL1741SB Rule 21, RSD NEC 2020:690.12, AFCI NEC 2020:690.11 / UL1699B, GFDI NEC 2020:690.41(B), CSA 22.2.107.1, CSA 22.2.330
  • Grid connection - IEEE 1547.1:2020;IEEE 1547:2018, Hawaii Rule 14H, California Rule 21 Phase I, II, III
  • EMC - FCC Part 15 Class B
  • Outdoor Rating - NEMA 4X / IP65
  • CEC Solar Equipment Listing

Power Pro - Comprehensive Certifications

  • UL9540A Certified, UL1973
  • UL9540 for PowerPro ESS
    • CN: 5026744
  • Outdoor Rating IP65
Product Image Product Information

1 X EG4 18KPV Hybrid Inverter | All-In-One Solar Inverter | 18000W PV Input | 12000W Output

Introducing the EG4 18kPV All-In-One Hybrid Inverter - the ultimate power solution for any solar project! This innovative hybrid inverter combines the functionality of a grid-tied and off-grid system together while eliminating the need for charge controllers or transformers to create a convenient, independent, all-purpose powerhouse. It also boasts an extensive list of certifications and compliances, helping it meet typical electrical regulations.

EG4 PowerPro WallMount AllWeather Lithium Battery | 48V 280Ah | 14.3kWh LiFePO4 | All-Weather Energy Storage

Battery Options:

  • 1 X EG4 PowerPro WallMount AllWeather Lithium Battery
  • 2 X EG4 PowerPro WallMount AllWeather Lithium Battery W/ 1 X EG4 PowerPro Battery Paralleling Cable
  • 3 X EG4 PowerPro WallMount AllWeather Lithium Battery W/ 2 X EG4 PowerPro Battery Paralleling Cable

1 x EG4 PowerPro Conduit Box(One for EACH battery)

The EG4 PowerPro Conduit Box offers a sturdy electrical solution, comprising a conduit box with nine plugs featuring grommets, along with adaptable cable glands for 1-2.5 inch knockouts. With compact dimensions of 24 x 10 x 9.9 inches, it serves as a versatile enclosure for various applications.

Tools & Addtional Components

✔ 1 x Staubli MC4 Branch Plug and Socket

✔ 1 x Wire Ratchet and Crimp Tool | MC4-Style

✔ 1 x Staubli Open End Spanner Set

✔ 1 x Cable Cutter | QuickCable 4275 | 4 AWG to 2/0 AWG
Wiring and Safety Components

Wiring & Safety Components

✔ 2 X Midnite Solar Surge Arrestors - 300 VDC

✔ Midnite Solar Surge Arrestors - 600 VDC (2 for Boviet)

✔ 1 X IMO 4-pole - DC Disconnect Isolator

✔ 7ft 10 AWG Copper PV Wire, Black and Red Set - (2 - CS Panels, 3 - Solarever Panels)

Wire Options:

4 X 50ft 10 AWG Copper PV Wire, Black and Red Set
4 X 100ft 10 AWG Copper PV Wire, Black and Red Set
Panel Options Product Information

32 X Boviet 450W Bifacial Solar Panel (Silver)

DESIGNED TO PERFORM AND BUILT TO LAST

PERC, half-cut, multi-busbar, and large cell designs enables:

  • The PV modules to pack more power per module
  • Produce more energy
  • Provide reliable,dependable system performance under different installations requirements, difficult weather, or environmental conditions.
